1.  Size: 1420 * 340 * 1000 mm (can be customized)

2. Lane width: 600 mm (standard) 900 mm( Handicapped)

3. Passing speed: 30 person/min

4. Power supply: 110 V/220 V 50/60 Hz

5. Brushed Driving Motor: 30 W

6. Gate Open Signal: Dry Contact/ Relay

7. Driving Motor: DC24V

8. Sliding turnstile Weight: 70 kg/pcs

9. Arm height: 1200 mm (can be customized)

CE Certificated, ISO9001 Certificated.

MT247 Sliding Turnstile Gate Brochure

Last updated on: April 27th, 2024 16:57 pm

AUTOMATIC TURNSTILE GATE SLIDING TURNSTILE MT247 carries a 2-year warranty and durable maintenance and repair support.

We can provide OEM and ODM services. We also provide biometric devices, such as IC/ID card readers, fingerprint scanners, QR code scanners, face recognition cameras, and so on. MairsTurnstile as a professional turnstile gate manufacturer, provide a variety of turnstile for sale at an affordable price. Wholesale and Retail Turnstile for sale.

An automated turnstile gate is a kind of pedestrian turnstile gate equipment, which is driven by a motor. It is also called electric turnstiles. Compared with manual turnstile gate, all the operation of the automatic turnstile gate is driven by the motor, and automatic turnstile gate has higher safety factor and credibility.

Automatic turnstile gate sliding turnstiles are an ideal solution for the metro station, stadiums, factories, or commercial buildings. Flap barrier is well adopted in entrances and exits of buildings or construction sites, to help to track staff and visitors. Only authorized users are able to access specific areas through the flap barrier sliding turnstile for sale. RFID, fingerprint verification, face recognition with temperature check, and vein verification technologies are available for options of flexibility.

sliding turnstile 4 sliding turnstile 5
  • Automatic turnstile gate is constructed to control people entering or exiting the restricted area. It is usually used in high pedestrian traffic flow locations in both directions.
  • The flap barrier automatic turnstile gate casing is made of brushed 304 stainless steel which creates a seamless and nice entrance system to blend into most indoor environments.
  • It can be integrated with all third-party access control systems (e.g.: RFID access system, Push the button, Fingerprint and face recognition with temperature check).
  • In case of emergency, the Sliding Turnstile arm will open automatically connecting with the battery or capacitor to allow free passage.
  • Optical Flap barrier sliding turnstiles are suitable for luxury and elegant entrance solutions.
  • The automatic turnstile gate features fast speed, long life, high performance, and high operation dependability.
  • Alarm function, in case of illegal intrusion and reverse intrusion.
  • The infrared sensor will alarm and the LED light will flash to prevent pinching pedestrians.
  • Automatic reset function: sliding arms will close automatically within 5s in default (can be set) if a passenger delays to
  • The flap barrier turnstiles will stay in the lock if someone wants to burst in without swiping the RFID card.
  • The LED directional indicator on the top and front post.
  • Arm height from the ground: 1200 mm
  • Arms material: acrylic/tempered glass
  • Options: LED on sliding door
  • Casing Material: 304 stainless steel
  • Casing Material: 304 stainless steel
  • Reliability of the mechanism: 3 million-5 million, no-fault
  • Sensors: 5 pairs
  • Size and material thickness can be customized
  • Working Direction: Bidirectional/Single directional
  • Humidity: ≤90%
  • Working temperature: -20℃~60℃
  • Communication distance: ≤1200 m
  • Communication interface: RS485
  • Feature: IC/ID reader, Barcode Reader, Face recognition, Fingerprint, other access control equipment, UPS, etc
  • The time needed for opening: 0.2 s
  • Working environment: Indoors
  • Up and down sliding mechanism
  • Feature: Rebound against resistance, fire alarm interface, automatic open when power off
  • Application range: Community, Factory, Construction site, School, Place of the resort, etc
  • Anti-reverse function, the turnstile alarms if someone wants to enter in the reverse direction.
  • Bi-direction or single-direction running are options.

We can provide the entire security access control solution. If you have your own access control system, you can directly use our turnstile gate. If you don’t have one, we also provide a complete security access control solution. Please refer to the video below for details.
