1. Size: 1000*300*1000 mm (can be customized)

2. Lane width: 550 mm (standard) Customized 900 mm( Handicapped)

3. Passing speed: 35 person/min

4. Power supply: 110V/220V 50/60Hz

5. Driving Motor: 90W

6. Input: 12V Dry Contact relay

7. Driving Motor: DC24V

8. Mechanism: DC brushed motor mechanism

9. Arm height from the ground: standard 1500 mm( 1800 mm max)

10. Arms material: 10mm acrylic (tempered glass option)

11. With 6pairs of sensors

Last updated on: June 19th, 2022 23:45 pm

FULL HEIGHT SLIDING GATE TURNSTILE MT224-P carries a 2 years warranty and durable maintenance and repair support.

We can provide OEM and ODM services. We also provide biometric devices, such as IC/ID card readers, fingerprint scanners, QR code scanners, face recognition cameras, and so on.

FULL HEIGHT SLIDING GATE TURNSTILE WITH RFID Access Control System for Amusement Park.

FULL HEIGHT SLIDING GATE TURNSTILE MT224-P offers a reliable and efficient method to ensure only authorized users are allowed access to each area of a building. A direction indicator showed that pedestrian access to the current status of, and guide pedestrian correct and smooth passage. The flap barrier gate is high integrated for every access control system, such as facial recognition with temperature check devices, fingerprints, QR code readers, RFID systems, etc.

  • Flap barrier sliding gate turnstile is constructed to control people entering or exiting the restricted area. It is usually used in high pedestrian traffic flow locations in both directions.
  • Casing Material: 304 stainless steel and black acrylic
  •  Reliability of the mechanism: 3 million-5 million, no-fault
  • Lane width 900 mm can be customized
  • Weight: 70 kg/pcs
  • Working Direction: Bidirectional/Single directional
  • Emergency situation: open automatically when the electricity is cut off with a capacitor
  • Humidity: ≤90%
  • Working temperature: -20℃~60℃
  • Communication distance: ≤1200 m
  • Communication interface: RS485
  • Feature: IC/ID reader, Barcode Reader, Face recognition, Fingerprint, other access control equipment, UPS, etc
  • The time needed for opening: 0.2 s
  • Working environment: Indoors
  • Application range: Community, office building, School, Place of the resort, government facility, etc
  • This flap barrier sliding gate turnstile casing is made of brushed 304 stainless steel which creates a seamless and nice entrance system to blend into most indoor environments.
  • It can be integrated with all third-party access control systems (e.g.: RFID access system, Push the button, Fingerprint and face recognition with temperature check).
  • In case of emergency, the FlapTurnstile arm will open automatically connecting with the battery or capacitor to allow free passage.
  • Optical Flap Barrier Turnstiles are suitable for luxury and elegant entrance solutions.
  • The flap turnstile features fast speed, long life, high performance, and high operation dependability
  •  Alarm function, in case of illegal intrusion and reverse intrusion.
  • The infrared sensor will alarm and the LED light will flash to prevent pinching pedestrians.
  • Automatic reset function: flap arms will close automatically within 5s in default (can be set) if passenger delays to
  • The flap turnstile will stay in the lock if someone wants to burst in without swiping the RFID card.
  • LED directional indicator on top and front post
  • Anti-reverse function, the turnstile alarms if someone wants to enter in the reverse direction.
  • Bi-direction or single-direction running are options

sliding gate turnstile

flap barrier turnstile casesturnstile gate access control systemturnstile gate package
