Sale!

OPTICAL SWING TURNSTILE MT353

$1,750.00 $1,300.00

  1. Size: 1500 * 150 * 1000 mm
  2. Lane Width: 600 mm (Standard)  900 mm( Handicapped)
  3. Arm material: Acrylic
  4. Passing speed: 40 person/min
  5. Power supply: 110 V/220 V 50/60 Hz
  6. Brushless motor : 40W
  7. Gate Open Signal: Dry Contact/ Relay
  8. Optical swing turnstile Driving Motor: 24V

Last updated on: December 18th, 2020 19:49 pm

OPTICAL SWING TURNSTILE carry a 2 years warranty and durable maintenance and repair support.

We can provide OEM and ODM service.

Swing Barrier Turnstile Access Control Facial Recognition RFID for Airports

Optical swing turnstile controls the people enter or exit the restricted area. The casing is high quality brushed 304 stainless steel. The mechanism uses cutting edge technology to min the size but ensure high performance. They are also equipped with a famous brand DC brushless motor and sophisticated sensor.   Swing turnstile gate has a standard relay output, which can be easily integrated with all kinds of third party access control system(i.e RFID, Fingerprint, Face, Barcode, IR thermometer). It is easy to setup multi-lanes

  • In case of emergency, cut off the power, the Slim swing turnstile will open automatically to allow free passage which is complying with fire safety requirements. But it has to comes with a battery. As for export, the battery is sensitive, we can use the capacitor to replace
  • Optical Swing Turnstile is suitable for luxury and high-end entrance solutions.
  • The whole system runs smoothly, low noise, high speed.
  • Alarm function, if there is an illegal intrusion and reverse intrusion, the gate will alarm and the door will lock.
  • There are a total of 6pairs of infrared sensor The middle sensors is to prevent pinch pedestrians.
  • Anti-tailing function, one person can pass in one time. If someone tails after the front people, the gate will alarm
  • LED indicator. Red cross and green arrow. There are also LED indicators on the front post.  The LED light can be added to the arms.
  • Bi-directional access reduces the need for more gates. It is accommodated for wheel Chair, shopping stroller increases the passing efficiency.
  • Automatic reset function. If the people did not pass within the preset time (default time is 5 seconds), the system will cancel the authority of the user and close automatically
  • Anti-bump, Anti clamp, The gates come with a brushless motor. During operation, if someone hits the arm, the gate will reset automatically. This function effectively prevents pedestrians especially children from bumping, clipping, striking, etc.

Turnstile Dimension:

MT353



access control system turnstile gatepackaging from Mairsturnstile

Feature

Single Core
Double Core(+$600)
